Ultimate Compact Design, Measuring W 2.1" x H 3.5" x D 1.2" (52 x 90 x 30 mm)
One Watt Powerful Audio Output and Clear Audio from the 1.4" Front Speaker
5 Watts of Reliable RF Power within a Compact body
Three Selectable TX Power settings (5 W (High)/2.5 W (Middle)/0.5 W (Low))
Over 15 hours Operating time with Supplied 1,750 mAh Li-ion Battery pack*1
3.5-Hour Rapid Charger (SBH-22) Included (Using SBR-28LI)
QRK (Quick Recall Key) : Two User Programmable Keys for Quick Access to Favorite Functions
One-touch Alarm and Quick HOME Channel Access for Emergency Signaling
Versatile Scanning Capabilities: VFO Scan, Memory Scan, Programmable memory scan (PMS), Memory bank scan, and Dual receive
Large-capacity 200 memory channels
3 home channels and 10 pairs of PMS memory channels
Selectable Frequency Steps(5/10/12.5/15/20/25/50/100 kHz )
Split Memory(Two different frequencies(TX/RX) )
WX Channels with "Severe Weather" Alert
VOX Operation with Optional VOX Earpiece Microphone (SSM-512B)
PC Programmable with Optional Programming Cable (SCU-35)
Transceiver-to-Transceiver Cloning with Optional Cloning Cable (SCU-36)
FM Broadcast Receiver Equipped
ARTS (Automatic Range Transponder System)
DTMF Operation
CTCSS/DCS Operation
Busy Channel Lock-Out (BCLO)
Battery Saver Function
Automatic Power-Off (APO) Feature
Transmitter Time-Out-Timer (TOT)
*1 (Tx) 5 : (Rx)5 : (Standby) 90 Duty Cycle
Supplied Accessories:
Antenna (SRA-15)
7.4 V 1,750 mAh Lithium-ion Battery Pack (SBR-28LI)
Rapid Charger (SBH-22)
AC Adapter (SAD-20)
Belt Clip (SHB-18)
Operating Manual
Specifications:
Frequency Ranges:
RX 136 - 174 MHz
RX 400 - 480 MHz
RX FM Broadcast 65 - 108 MHz
TX 144 - 148 MHz
TX 430 - 450 MHz
Circuit Type: Direct-Conversion Modulation Type: F2D, F3E, F2A RF Power Output: 5 W/2.5 W/0.5 W AF Audio Output: 1 W (Max power) Case Size (W x H x D): 2.1" x 3.5" x 1.2" (52 x 90 x 30 mm) without Knob Weight (Approx.): 8.82 oz (250 g) with SBR-28LI and Antenna
